How to Compress API Functions with Brotli, Gzip, or LZ-String

For normal HTTP API responses, use Brotli or gzip as HTTP content encodings. The client advertises supported encodings with Accept-Encoding; the server compresses the representation and identifies the result with Content-Encoding. Use LZ-String only when your API contract intentionally carries an application-level encoded string or byte representation. LZ-String is not a drop-in HTTP content encoding.

In Node.js, the built-in node:zlib module supports gzip and Brotli. Express applications can use the compression middleware. For LZ-String, both sides must agree on the exact output format and matching decompression method.

Choose the right compression layer

Decision	Brotli	gzip	LZ-String
Layer	HTTP content encoding	HTTP content encoding	Application-level representation
Negotiated with Accept-Encoding?	Yes	Yes	No
Node.js implementation	zlib.createBrotliCompress() or Express middleware	zlib.createGzip() or Express middleware	lz-string paired methods
Typical use	HTTP responses when the client supports br	Broad HTTP compatibility	Compact strings in a deliberately defined payload format
Main concern	Measure quality, CPU, and client support	Choose a level and measure CPU versus size	Format and decoder compatibility across languages

Do not claim one is universally smallest or fastest. The primary documentation does not establish a directly comparable Brotli-versus-gzip-versus-LZ-String benchmark for API JSON. Measure representative payloads in your own runtime and traffic pattern.

How HTTP response compression works

1. The client sends an Accept-Encoding header, such as br, gzip.
2. The server selects an encoding it supports and that the client accepts.
3. The server compresses the response bytes.
4. The server sends Content-Encoding: br or Content-Encoding: gzip.
5. If caches can store either compressed or uncompressed representation, the response should include Vary: Accept-Encoding.

Never set Content-Encoding unless the bytes have actually been encoded. A mislabeled response causes clients to attempt the wrong decompressor and usually produces corrupted output or a decoding error.

Node.js: compress a response with Brotli or gzip

The following server chooses Brotli when the request advertises br, gzip when it advertises gzip, and otherwise sends plain JSON. It uses streaming APIs so large responses do not need to be assembled into one additional compressed buffer.

import http from 'node:http';
import { promisify } from 'node:util';
import { createGzip, createBrotliCompress, constants } from 'node:zlib';

const payload = JSON.stringify({
  ok: true,
  items: Array.from({ length: 1000 }, (_, id) => ({ id, name: `item-${id}` }))
});

const pipeline = promisify((...args) => import('node:stream').then(({ pipeline }) => pipeline(...args)));

function accepts(acceptEncoding, name) {
  return acceptEncoding
    .split(',')
    .map(part => part.trim().split(';')[0].toLowerCase())
    .includes(name);
}

const server = http.createServer(async (req, res) => {
  const accepted = req.headers['accept-encoding'] || '';
  res.setHeader('Content-Type', 'application/json; charset=utf-8');
  res.setHeader('Vary', 'Accept-Encoding');

  try {
    if (accepts(accepted, 'br')) {
      res.setHeader('Content-Encoding', 'br');
      const compressor = createBrotliCompress({
        params: { [constants.BROTLI_PARAM_QUALITY]: 5 }
      });
      await pipeline(ReadableFromString(payload), compressor, res);
      return;
    }

    if (accepts(accepted, 'gzip')) {
      res.setHeader('Content-Encoding', 'gzip');
      await pipeline(ReadableFromString(payload), createGzip(), res);
      return;
    }

    res.end(payload);
  } catch (error) {
    if (!res.headersSent) res.writeHead(500);
    res.end('compression failed');
  }
});

function ReadableFromString(value) {
  const { Readable } = require('node:stream');
  return Readable.from([value]);
}

server.listen(3000, () => console.log('http://localhost:3000'));

For production code, use the stream utilities from your deployed Node.js version and test the error path. The Node.js zlib documentation covers the current APIs, supported encodings, Brotli parameters, and decompression behavior: Node.js zlib documentation.

A simpler buffer-based example

Buffer APIs are convenient for small, already-materialized responses:

import { gzip, brotliCompress } from 'node:zlib';
import { promisify } from 'node:util';

const gzipAsync = promisify(gzip);
const brotliAsync = promisify(brotliCompress);
const body = Buffer.from(JSON.stringify({ message: 'hello' }));

const compressed = await brotliAsync(body);
console.log(compressed.length);

For repeated content, cache the compressed representation instead of recompressing identical bytes on every request. Node.js notes that zlib work can be expensive and that asynchronous operations use the internal threadpool. Large numbers of concurrent zlib objects can also increase memory pressure.

Express: enable compression middleware

Install the middleware:

npm install compression

Then place it before routes whose responses should be compressed:

import express from 'express';
import compression from 'compression';

const app = express();

app.use(compression({
  // -1 uses the package's default gzip compromise.
  level: -1,
  // The documented default is 1 KB. Set your own policy explicitly if needed.
  threshold: '1kb',
  filter: (req, res) => {
    if (req.headers['x-no-compression']) return false;
    return compression.filter(req, res);
  }
}));

app.get('/api/data', (req, res) => {
  res.json({ items: Array.from({ length: 1000 }, (_, id) => ({ id })) });
});

app.listen(3000);

Express’s compression middleware documentation describes support for gzip, Brotli, and deflate. Its default filter checks whether the response content type is compressible, and its documented threshold is 1 KB. Threshold behavior is advisory when the body length is unknown by the time headers are committed.

Choosing Express settings

• Threshold: Skip tiny responses where headers cost more than compression saves. Remember that streaming responses may not have a known length.
• Gzip level: Higher levels can reduce size at the cost of more CPU and latency; lower levels favor speed. Express documents levels 0 through 9 and -1 as the default compromise.
• Filter: Skip already-compressed formats, streaming endpoints with special requirements, or responses where compression is not useful.
• Brotli parameters: Treat quality settings as workload-specific. Node.js v26 documentation describes quality 6 as suitable for streaming and quality 11 as intended for offline or build-time compression; verify guidance against your deployed runtime.

Testing compressed responses with cURL, Python, and Node.js

cURL

curl --compressed -i http://localhost:3000/api/data

--compressed asks cURL to advertise supported encodings and decompress the response for display. To inspect headers while saving the decoded body:

curl --compressed -D headers.txt http://localhost:3000/api/data -o data.json
cat headers.txt

Python

import requests

response = requests.get('http://localhost:3000/api/data', timeout=30)
response.raise_for_status()
print(response.headers.get('Content-Encoding'))
print(response.json())

Most Python HTTP clients transparently decode gzip and Brotli when the relevant optional support is installed. If you need raw compressed bytes, disable automatic decoding in the specific client you use and document that behavior.

Node.js client

const response = await fetch('http://localhost:3000/api/data', {
  headers: { 'Accept-Encoding': 'br, gzip' }
});

console.log(response.headers.get('content-encoding'));
const data = await response.json();
console.log(data.items.length);

LZ-String for an application-level contract

LZ-String is useful when the encoded value itself is part of your application protocol—for example, a compact state value in a URL or a text-only field. It does not participate in HTTP negotiation, and you should not label an LZ-String value as Content-Encoding: gzip or br.

npm install lz-string

import LZString from 'lz-string';

const source = JSON.stringify({ filters: ['open', 'recent'], page: 2 });

const base64 = LZString.compressToBase64(source);
const restoredBase64 = LZString.decompressFromBase64(base64);

const uriValue = LZString.compressToEncodedURIComponent(source);
const restoredUri = LZString.decompressFromEncodedURIComponent(uriValue);

const utf16 = LZString.compressToUTF16(source);
const restoredUtf16 = LZString.decompressFromUTF16(utf16);

const bytes = LZString.compressToUint8Array(source);
const restoredBytes = LZString.decompressFromUint8Array(bytes);

console.log(restoredBase64 === source);
console.log(restoredUri === source);
console.log(restoredUtf16 === source);
console.log(restoredBytes === source);

The project documents raw, Base64, URI-safe, UTF-16, and Uint8Array methods and their paired decompressors in its official repository. Raw compressed output is not safe for arbitrary text storage. For a multi-language API, specify the exact format, character or byte transport, package expectations, and test vectors. Ports maintained by other developers are separate implementations, so verify compatibility rather than assuming identical behavior.

Designing a reliable compression policy

1. Define representations: Decide which media types are compressible and which formats are already compressed, such as JPEG, PNG, WebP, ZIP, or PDF.
2. Negotiate correctly: Honor Accept-Encoding, send the matching Content-Encoding, and add Vary: Accept-Encoding when caches may store alternate representations.
3. Set a minimum size: Use a threshold based on measured header overhead and payload sizes.
4. Cache repeated output: Cache compressed bytes when the payload, encoding, and relevant headers are stable.
5. Stream large bodies: Use streaming zlib APIs and a pipeline so backpressure and errors are handled.
6. Measure under concurrency: Record response size, time to first byte, total latency, CPU, memory, runtime version, compression settings, and client mix.
7. Validate every decoder: Include tests for empty bodies, Unicode, malformed data, truncated streams, and content types that should remain uncompressed.

Common errors and fixes

Symptom	Likely cause	Fix
Browser reports decoding failure	Content-Encoding does not match actual bytes	Set the header only after selecting and applying the compressor; verify with cURL.
Cached clients receive the wrong variant	Cache ignores Accept-Encoding	Send Vary: Accept-Encoding and configure the intermediary cache.
Small responses are slower	Compression overhead exceeds the size saved	Raise the threshold or skip tiny responses.
CPU spikes under load	High compression quality or too many concurrent zlib jobs	Lower quality, limit concurrency, cache repeated results, and measure again.
LZ-String returns null or corrupted text	Wrong paired format or incompatible port	Use the matching decompressor and publish test vectors in the contract.
JSON is still large	Payload contains long keys, repeated metadata, or already-compressed values	Measure serialization and schema changes separately; do not expect compression to fix an oversized data model.
Streaming response is truncated	Pipeline or compressor errors are not propagated	Use a stream pipeline, listen for errors, and avoid writing a success status before compression can fail.

Performance, reliability, and cost notes

Compression trades network transfer for compute and memory. Benchmark with production-shaped JSON, realistic response sizes, concurrency, and client distribution. Record the Node.js version and all quality or level parameters. A result measured on one payload cannot establish a universal winner.

Compression does not remove the need for timeouts, retries, cancellation, backpressure, and observability. Log the selected encoding, uncompressed and compressed byte counts where practical, compression duration, and failures. Keep an uncompressed path for clients that advertise no supported encoding.

If your API sends secrets alongside attacker-controlled values, review your application security rules before compressing them together. The referenced documentation does not establish a security guarantee for that scenario.
