How to Configure KnpSnappyBundle Options

Direct answer: configure KnpSnappyBundle in config/packages/knp_snappy.yaml. Define separate pdf and image sections, point them to the actual wkhtmltopdf and wkhtmltoimage executables, and put renderer flags in each section’s options array.

# config/packages/knp_snappy.yaml
knp_snappy:
    pdf:
        enabled: true
        binary: /usr/local/bin/wkhtmltopdf
        options: []
    image:
        enabled: true
        binary: /usr/local/bin/wkhtmltoimage
        options: []

Use the real paths from the environment where Symfony runs. The paths above are examples only.

1. Install the bundle

composer require knplabs/knp-snappy-bundle

With Symfony Flex, the bundle is normally registered by the recipe. Without Flex, add it to config/bundles.php:

<?php

return [
    Knp\Bundle\SnappyBundle\KnpSnappyBundle::class => ['all' => true],
];

2. Configure PDF and image services

The two services are independent. Enable only the renderer your application needs.

KnpSnappyBundle routes PDF and image jobs to separate renderer services.

Section	Executable	Typical output
`pdf`	`wkhtmltopdf`	PDF documents
`image`	`wkhtmltoimage`	JPEG, PNG or other formats supported by the installed binary

knp_snappy:
    pdf:
        enabled: true
        binary: '%env(WKHTMLTOPDF_PATH)%'
        options:
            page-size: A4
            margin-top: 12mm
            margin-right: 12mm
            margin-bottom: 12mm
            margin-left: 12mm
    image:
        enabled: false
        binary: '%env(WKHTMLTOIMAGE_PATH)%'
        options:
            format: png
            width: 1440

Environment variables keep machine-specific executable paths out of committed configuration:

# .env.local
WKHTMLTOPDF_PATH=/usr/local/bin/wkhtmltopdf
WKHTMLTOIMAGE_PATH=/usr/local/bin/wkhtmltoimage

On Windows, quote paths containing spaces and escape them according to your YAML syntax:

knp_snappy:
    pdf:
        enabled: true
        binary: 'C:\\Program Files\\wkhtmltopdf\\bin\\wkhtmltopdf.exe'
        options: []

3. Set temporary storage and process limits

KnpSnappyBundle uses sys_get_temp_dir() by default. Set temporary_folder when the default directory is not writable, is too small, or should be isolated per application. process_timeout is measured in seconds.

knp_snappy:
    temporary_folder: '%kernel.cache_dir%/snappy'
    process_timeout: 20
    pdf:
        enabled: true
        binary: '%env(WKHTMLTOPDF_PATH)%'
        options: []
    image:
        enabled: true
        binary: '%env(WKHTMLTOIMAGE_PATH)%'
        options: []

Create the directory and ensure the PHP worker user can write to it. Choose a timeout based on your page size, remote assets and queue or HTTP deadline; 20 seconds is an example, not a universal recommendation.

4. Pass wkhtmltopdf and wkhtmltoimage options

The options array becomes renderer arguments. Option names are written without the leading --. For example, disable-javascript: true maps to --disable-javascript.

knp_snappy:
    pdf:
        enabled: true
        binary: '%env(WKHTMLTOPDF_PATH)%'
        options:
            disable-javascript: false
            no-background: false
            allow:
                - '%kernel.project_dir%/public'
            cookie:
                - 'session_id abc123'
            cache-dir: '%kernel.cache_dir%/wkhtmltopdf'
    image:
        enabled: true
        binary: '%env(WKHTMLTOIMAGE_PATH)%'
        options:
            format: jpeg
            quality: 90
            width: 1600
            javascript-delay: 500

Options such as disable-javascript, no-background, allow, cookie, post, cover, toc and cache-dir are renderer examples. Exact behavior depends on the installed binary, so inspect its help output and version before relying on a flag.

wkhtmltopdf --version
wkhtmltopdf --extended-help
wkhtmltoimage --version
wkhtmltoimage --extended-help

5. Use the bundle services in Symfony

The integration exposes knp_snappy.pdf and knp_snappy.image. Generate from a URL or from HTML.

Generate a PDF from a URL

<?php

namespace App\Controller;

use Knp\Snappy\Pdf;
use Symfony\Component\HttpFoundation\Response;
use Symfony\Component\Routing\Annotation\Route;

final class InvoiceController
{
    #[Route('/invoice/{id}.pdf')]
    public function pdf(string $id, Pdf $pdf): Response
    {
        $url = 'https://example.com/invoices/' . rawurlencode($id);
        $content = $pdf->getOutput($url);

        return new Response($content, 200, [
            'Content-Type' => 'application/pdf',
            'Content-Disposition' => 'inline; filename="invoice-' . $id . '.pdf"',
        ]);
    }
}

Generate from rendered HTML

use Knp\Snappy\Pdf;
use Symfony\Component\HttpFoundation\Response;

public function statement(Pdf $pdf): Response
{
    $html = $this->renderView('statement/pdf.html.twig', [
        'account' => $account,
    ]);

    return new Response(
        $pdf->getOutputFromHtml($html),
        200,
        ['Content-Type' => 'application/pdf']
    );
}

Generate an image

use Knp\Snappy\Image;
use Symfony\Component\HttpFoundation\Response;

public function preview(Image $image): Response
{
    $bytes = $image->getOutputFromHtml('<h1>Preview</h1>');

    return new Response($bytes, 200, [
        'Content-Type' => 'image/jpeg',
    ]);
}

For larger files, write output to a controlled temporary path and stream it instead of holding multiple documents in memory.

6. Choose options by workload

PDF layout: set page size, margins, orientation and any header or footer options supported by your binary.
Images: set format, quality, width or height, and a delay when client-side rendering needs time.
Assets: use allow for narrowly scoped local directories and verify that CSS, fonts and images are reachable.
Authentication: use renderer cookie or post options only for controlled values; never concatenate untrusted input into command arguments.
JavaScript: keep it enabled only when required. Pages using modern ES6 APIs may fail because wkhtmltopdf is not fully compatible with them; polyfills can help in some applications.

7. Security checklist

Do not enable --enable-local-file-access broadly for untrusted HTML or JavaScript. Snappy documentation warns that local files or remote code execution may be exposed.
Prefer allow-listed asset directories over unrestricted filesystem access.
Keep user-controlled URLs, cookies and headers out of shell strings; pass them through the bundle’s structured options.
Run the renderer with a restricted OS user and writable temporary directory only.
Validate destination URLs and block internal network ranges when rendering user-supplied URLs.

8. Troubleshooting

Symptom	Likely cause	Fix
Executable not found	Wrong `binary` path or missing package	Run `command -v wkhtmltopdf`, copy the absolute path, and verify the PHP worker sees the same filesystem.
Permission denied	Binary or temporary directory is inaccessible	Grant execute permission to the binary and write permission to `temporary_folder`.
Process timed out	Slow remote assets, JavaScript or an undersized timeout	Inspect the URL independently, reduce unnecessary resources, add a bounded delay, or increase `process_timeout` to match your workload.
Blank PDF or image	Assets blocked, page requires authentication, or rendering starts before content appears	Check cookies and URLs, use `allow` for required local assets, and confirm the page works with the same renderer command.
Modern frontend fails	Incompatible ES6 API or JavaScript dependency	Provide compatible bundles or polyfills, disable JavaScript where possible, or use a renderer designed for the page.
Local images or fonts missing	Local file access is disabled or paths are outside allowed directories	Use a narrow `allow` path and ensure URLs resolve from the renderer’s process.
Configuration changes ignored	Cached Symfony container	Clear the environment cache and confirm the active environment loads the expected YAML file.

9. Performance and reliability

Reuse a stable renderer installation and keep temporary storage on a fast local disk.
Reduce page weight, third-party requests and JavaScript work before increasing timeouts.
Separate interactive HTTP requests from bulk document generation with a queue.
Record renderer exit codes and stderr so failures can be diagnosed instead of retried blindly.
Use deterministic HTML, pinned asset versions and explicit fonts when output must be reproducible.
Test the exact PHP, Symfony, Snappy and renderer versions together. Package metadata changes over time; verify the registry and lockfile before publishing version-specific requirements.

10. When an API is simpler

KnpSnappyBundle is useful when your Symfony application must own the renderer process. If you only need a website screenshot, a hosted API removes binary installation, process management and browser setup.

A hosted screenshot API can clean common overlays before capture.

Or skip the browser setup

ScreenshotNeo provides one GET request for a PNG, JPEG, WebP or PDF. See the API documentation for all options.

curl -G "https://api.screenshotneo.com/v1/shot" -d access_key=YOUR_API_KEY --data-urlencode url=https://stripe.com -o shot.webp

import requests

r = requests.get(
    "https://api.screenshotneo.com/v1/shot",
    params={"access_key": "YOUR_API_KEY", "url": "https://stripe.com"},
    timeout=90,
)
r.raise_for_status()
open("shot.webp", "wb").write(r.content)

const q = new URLSearchParams({ access_key: 'YOUR_API_KEY', url: 'https://stripe.com' });
const res = await fetch(`https://api.screenshotneo.com/v1/shot?${q}`);
if (!res.ok) throw new Error(`HTTP ${res.status}`);
const bytes = new Uint8Array(await res.arrayBuffer());

ScreenshotNeo removes cookie banners, newsletter popups and chat widgets before capture. Bot checks, blank pages and failed loads are never billed, and response headers identify the page verdict and whether it was billed. Its MCP server lets Claude, Cursor and other MCP clients call take_screenshot, get_page_info and capture_pdf. The free plan includes 1,000 screenshots per month without a card; paid plans start at $5 for 3,000 shots.

Create a free ScreenshotNeo account.

FAQ

Can PDF and image rendering be configured separately?

Yes. Each section has its own enabled, binary and options values.

Where should renderer binaries live?

Anywhere the Symfony worker can execute them. Store the absolute path in an environment variable when paths differ by environment.

Is `process_timeout` a renderer timeout or an HTTP timeout?

It controls the bundle’s renderer process in seconds. Your web server, PHP-FPM and queue may impose separate limits.

Why does a page work in Chrome but fail in wkhtmltopdf?

wkhtmltopdf has different JavaScript and browser-engine support. Check ES6 compatibility, asset access and authentication using the installed binary itself.

Should I enable local file access?

Only when the input and allowed paths are controlled. Broad local-file access is unsafe for untrusted HTML or JavaScript.
